Phone Functions with Compatible Base Stations

Programmable Keys

• Line key
• KeyLine1
• Speed dial
• Busy phone monitoring2
• Paging zones
• Directory
• Additional functions in current and future software

Shared Calls

• All shared calls are visible and can be managed on all devices (up to 16)
• Phones are not limited to only 2 calls like traditional DECT devices

Other Features

• Barge-in
• Shared directory with up to 500 entries
• Shared central directories: LDAP, remote XML
• Private directory with up to 200 entries
• Caller identification (CLIP)
• Redial
• Call waiting
• Auto-answer (SIP and cradle pickup)
• Call lists (all calls, missed, received, dial calls)
• Hold (private or shared)
• Blind and attended transfer
• Call forwarding
• 3-way conference
• Missed call notification
• MWI – Voice message waiting indicator

Range

Indoors

• up to 50 meters

Outdoors

• up to 300 meters

User Interface

Display

• 2.4″ diagonal
• Resolution 240 x 320 pixels

Other Features

• Backlit dialpad
• 6 backlit dual color LED programmable keys
• 3 context-sensitive function keys
• 5-way navigation
• Speakerphone key with red LED when speakerphone is on
• Volume up/down on the side
• Page key on the side
• 1 red LED at the top for missed calls or new voice messages

DECT

Frequency Bands

• EU: 1880 – 1900 MHz
• US: 1920 – 1930 MHz

Output Power

• EU < 250mW
• US < 100 mW

Protocols

• DECT 6.0

Other Features

• Seamless handover and roaming
• Wideband audio
• Authentication/encryption of base and handset

Handset

Weight Approximately

• 188g (Handset with battery + belt clip)

Dimensions: Approximately

• 188mm x 55mm x 35mm with belt clip
• Connector: 3.5mm wired headset jack
• Hearing-aid compatible (HAC)
• Bluetooth for headset connection

Battery

• Type: Lithium-ion, 1500mAh, 3.7V, 5.55Wh
• Talk Time WB: Up to 12 hours
• Talk Time NB: Up to 19 hours
• Standby Time: Approximately 240 hours

Charger

Input

• Fixed USB type A cable

Charging Indicator

• Red LED – light is on when handset is charging in cradle

Power Adapter

Input Power

• 100-240 AC Volt, 50/60Hz, 300mA

Output Power

• 5V 2A

Plug

• US type with USB type A output

Product Number

• 00004526

Compatible Base Station

• Snom M500 SIP DECT Multicell Base Station: 00004525 (US)

1. Refers to programmable key type that allows calls to be visible and accessible on different phones via key press. This is comparable to old key system operation.
2. Refers to programmable key type that allows indication if a phone is busy in a call. This is comparable to SIP BLF operation.
